Export Canvas to Image Without rendering it

Why Export Canvas Without Rendering?

Sometimes, you might want to create an image from your custom drawing logic or a widget without actually showing it on the screen. This is useful for generating thumbnails, sharing images in the background, or saving artwork.

Flutter provides a way to do this using ui.PictureRecorder and Canvas.

How to Export Your Canvas

You can capture the drawing commands you make on a Canvas using a ui.PictureRecorder. This recorder then gives you a ui.Picture which can be converted into a ui.Image.

The Process

1. Create a ui.PictureRecorder.
2. Create a Canvas using the recorder.
3. Apply the necessary transformations (like scaling for different device pixel ratios).
4. Use your CustomPainter (or direct drawing commands) to paint onto this canvas.
5. End the recording using recorder.endRecording() to get a ui.Picture.
6. Convert the ui.Picture to a ui.Image using picture.toImage(width, height).
7. Convert the ui.Image into a format like PNG (Uint8List) using image.toByteData(format: ui.ImageByteFormat.png).
8. Get the raw byte data.

Code Example

Future<Uint8List> toImage(BuildContext context, Size size) async {
  final devicePixelRatio = MediaQuery.of(context).devicePixelRatio;
  final recorder = ui.PictureRecorder();
  final canvas = Canvas(recorder);

  // important scale the canvas according to pixel ratio
  canvas.scale(devicePixelRatio);

  final painter = MyPainter(); // <-- this is your customPainter
  painter.paint(canvas, size);

  // export with according size
  final width = (size.width * devicePixelRatio).floor();
  final height = (size.height * devicePixelRatio).floor();

  // transform into a ui.image
  final imageResult = recorder.endRecording().toImage(width, height);

  // transform into a regular png byte array
  final byteData = await imageResult.toByteData(
    format: ui.ImageByteFormat.png,
  );

  return byteData!.buffer.asUint8List();
}

// PS: your canvas has to paint some things.
// Create your own CustomPainter first (MyPainter here)

This function gives you the image data as a list of bytes (Uint8List), ready to be saved to a file, uploaded, or processed further.

Important Note

You must have drawing logic to paint on the canvas. In the example above, this is done by a MyPainter (which you need to create yourself). The CustomPainter's paint method will receive the canvas and size to draw upon.
